PowerEdge R770
Drive efficiency in your datacenter through
maximum performance with optimized power.
Boost Datacenter Efficiencies and Performance
The Dell PowerEdge R770 is a 2U, dual-socket rack server designed for high performance computing with optimal
power efficiency and balanced performance to boost your data center productivity. It balances advanced computing
power with virtualization, artificial intelligence inferencing, cloud-native applications, hyperscale workloads, and scale
out databases.
Purpose-built for enterprise and scalable infrastructures, the PowerEdge R770 offers standardization that easily
integrates into existing environments, equipped with two Intel® Xeon® 6 processors with E-cores and P-cores it offers
up to 1.69x better performance per watt than previous models, improving power efficiency and increasing rack density.
The addition of GPU support further amplifies computational power, ensuring high performance with lower energy use.
These servers are available in rear I/O hot aisle and front I/O cold aisle configurations. The front I/O cold aisle
improves serviceability, reduces maintenance time, and enhances efficiency, reliability, and uptime, supporting your
sustainability goals by optimizing cooling and energy use. It also features Dell’s Smart Power and Cooling Technology,
optimized for air cooling to significantly reduce energy consumption, contributing to long-term operational savings.
Cyber Resilient Architecture for Zero Trust IT environment & operations
Security is integrated into every phase of the PowerEdge lifecycle, including protected supply chain and factoryto-site integrity assurance. The Silicon-based root of trust anchors end-to-end boot resilience while Multi-Factor
Authentication (MFA) and role-based access controls safeguard trusted operations.
Vendor: Dell
Unit type: Server
Type: 19" 2 HE
Model: PowerEdge R770
HDD bays: 16x HotSwap HDD Bays SAS/S-ATA /NVMe Backplane
without selected hdds or trays are no hdd trays included in delivery
Optical drive: ohne
Networking: optional selectable
Internal interfaces:
16x 2,5" SAS*/SATA*/NVMe** Backplane
*optional SAS storage controller required
**optional NVMe onboard cabling or NVMe storage controller required
2x FCLGA4710 Intel CPU Socket XEON 6 Intel® Xeon® Processors up to 350W TDP
32x DDR5 ECC DIMM banks up to 8TB RAM
1x OCP 3.0 module Slot
1x USB 3.0
integrated TPM 2.0
Default Riser Config 6:
Riser 1:
1x PCIe 5.0 x16 (x16 lanes) - Full-Profile, Full-Length (double-width) (CPU1)
Riser 2:
1x PCIe 5.0 x16 (x16 lanes) - Full-Profile, Half-Length (CPU1)
Riser 3:
1x second OCP3 module slot (PCIe 5.0 x16) (CPU1)
Riser 4:
1x PCIe 5.0 x16 (x16 lanes) - Full-Profile, Half-Length (CPU0)
Riser 5:
1x PCIe 5.0 x16 (x16 lanes) - Full-Profile, Full-Length (double-width) (CPU0)
External interfaces:
Front:
1x USB-C
Rear:
1x VGA
2x USB 3.0
1x RJ-45 iDRAC
Videocard: onboard
Powerunits: up to 2x HotSwap power supply
Compatible operating systems:
Windows: Windows Server 2016, 2019, 2022*, 2025*; Windows 10, 11*
*compatible TPM module is required
Virtualisierung: vmware ; Citrix ; Microsoft Hyper-V ; Proxmox; Linux KVM
Linux Betriebssysteme: Linux Suse, Linux RHEL (RedHat), Debian, Fedora etc.
Tailored to fit complex data centers
The Dell PowerEdge R770 is a 2U, two-socket rack server delivering exceptional performance and scalability transforming complex IT requirements of today’s data centers. It combines enhanced compute power, flexible configurations, and energy efficiency to boost productivity. This makes it ideal for virtualization and microservices, cloud-native applications, large-scale analytics, and AI inferencing support to empower your infrastructure.
• Purpose-built to scale infrastructure to adapt seamlessly to technological changes, integrating new capabilities that support long-term growth and innovation.
• Powered by Intel® Xeon® 6 processors designed to meet diverse performance and efficiency requirements and offered with advanced GPU support.
• Enhanced I/O flexibility with optional front I/O configuration for seamless cold aisle serviceability.
• Dell Smart Power and Cooling solutions allow you to choose air cooled or DLC solutions to fit your IT and data center requirements.
• Configurable to suit diverse needs with industry standard open designs (DC-MHS) compliance.
