Vendor: Dell
Unit type: Server
Type: 19" 2 HE
Model: PowerEdge R760xs
HDD bays: 8x HotSwap HDD Bays SAS/S-ATA Backplane
without selected hdds or trays are no hdd trays included in delivery
Optical drive: ohne
Networking: optional selectable OCP module
Internal interfaces:
2x FCLGA4677 Intel CPU Sockel 4th / 5th Generation Scalable Intel® Xeon® Processors
Intel® Series Chipset C741
16x DDR5 ECC DIMM banks, up to 1,5 TB
4 x PCIe Gen4 LP slots, Gen5 speed via optional Risers possible (up to 6x PCIe possible)
1x OCP 3.0 module slot
External interfaces:
2x USB 2.0 (1x front)
1x USB 3.0
2x RJ-45 1GbE onboard
1x RJ-45 Servermanagement IDRAC9 Port
2x VGA 15pol. D-SUB (1x rear, 1x front)
Videocard: onboard
Powerunits: up to 2x Dell HotSwap Power supply
Net weight: 13,37 kg
Installation depth: 71,5 cm
Dimensions: L: 71,5 cm | B: 48,3 cm | H: 8,8 cm
Compatible operating systems:
Windows: Windows Server 2016, 2019, 2022*; Windows 10, 11*
*compatible TPM module is required
Virtualisierung: vmware ; Citrix ; Microsoft Hyper-V ; Proxmox; Linux KVM
Linux Betriebssysteme: Linux Suse, Linux RHEL (RedHat), Debian, Fedora etc.
Discover the Dell PowerEdge R760xs - Performance and Flexibility in Perfection
The Dell PowerEdge R760xs is a powerful 2U rack server specifically designed for demanding workloads and future-proof IT infrastructures. It is used in data centers and enterprise environments.
It is ideal for:
- Virtualization environments
- Database applications
- High-performance computing
- Cloud infrastructures
- Mission-critical applications
The backplane offers space for up to 8 hot-swappable 2.5-inch drives (SAS/SATA), which can be replaced during operation. This allows for easy maintenance and expansion of the storage system without compromising data availability.
The R760xs features two FCLGA4677 CPU sockets designed for scalable 4th and 5th generation Intel Xeon processors. Up to two of these powerful processors can be installed to provide high computing power and scalability. The server also offers the option to install an OCP network module of choice, which can be selected and added as needed. This option allows the server's networking capabilities to be adapted to specific requirements, ensuring flexibility for future network demands.
The server has a total of 16 memory slots for DDR5 RAM modules, which support ECC (Error-Correcting Code) DIMMs. This configuration allows for a maximum memory capacity of up to 1.5TB and ensures high reliability through error correction mechanisms. Using ECC DIMM memory modules helps detect and correct data integrity errors, improving system stability and reliability, particularly in mission-critical environments. With DDR5 ECC RAM, you are well-equipped for future applications and workloads.
The motherboard is based on the Intel C741 chipset, which manages communication between the various system components. The chipset provides functions such as data transfer, power management, and other system operations. The combination of scalable 4th/5th generation Intel Xeon processors, large memory capacity, and a powerful chipset provides a solid foundation for a high-performance server.
The server features four PCIe Gen4 slots in a low-profile format, suitable for a variety of expansion cards such as graphics and network cards. A standout feature is the ability to upgrade to PCIe Gen5 speeds through optional riser cards. Additionally, the Dell PowerEdge R760xs includes an OCP 3.0 module slot, enabling flexible integration of modern, high-performance network cards with speeds of up to 100GbE.
External USB 2.0/3.0 ports allow for the connection of peripheral devices or external hard drives, ensuring high-speed data transfer. Equipped with two RJ-45 1GbE ports and an RJ-45 server management iDRAC9 port, the server provides standard network connectivity as well as remote management and monitoring capabilities, increasing operational efficiency and minimizing downtime. Additionally, video output is supported via VGA.
The inclusion of redundant hot-swappable power supplies and fans ensures that these components can be easily replaced during operation, thereby increasing system reliability and simplifying maintenance. The list of compatible operating systems for the Dell PowerEdge R760xs includes various Windows versions such as Windows Server 2016, 2019, 2022, Windows 10, and 11. Additionally, virtualization platforms such as VMware, Citrix, Microsoft Hyper-V, Proxmox, and Linux KVM are supported. Linux operating systems such as SUSE, Red Hat Enterprise Linux (RHEL), Debian, and Fedora are also suitable. This compatibility enables the server to work with a wide range of operating systems and meet diverse requirements.
With the Dell PowerEdge R760xs, you are investing in a future-proof, high-performance, and flexible server solution that helps your business tackle the challenges of the digital era. Contact us today for a customized quote and take your IT infrastructure to the next level.
PowerEdge R770
Drive efficiency in your datacenter through
maximum performance with optimized power.
Boost Datacenter Efficiencies and Performance
The Dell PowerEdge R770 is a 2U, dual-socket rack server designed for high performance computing with optimal
power efficiency and balanced performance to boost your data center productivity. It balances advanced computing
power with virtualization, artificial intelligence inferencing, cloud-native applications, hyperscale workloads, and scale
out databases.
Purpose-built for enterprise and scalable infrastructures, the PowerEdge R770 offers standardization that easily
integrates into existing environments, equipped with two Intel® Xeon® 6 processors with E-cores and P-cores it offers
up to 1.69x better performance per watt than previous models, improving power efficiency and increasing rack density.
The addition of GPU support further amplifies computational power, ensuring high performance with lower energy use.
These servers are available in rear I/O hot aisle and front I/O cold aisle configurations. The front I/O cold aisle
improves serviceability, reduces maintenance time, and enhances efficiency, reliability, and uptime, supporting your
sustainability goals by optimizing cooling and energy use. It also features Dell’s Smart Power and Cooling Technology,
optimized for air cooling to significantly reduce energy consumption, contributing to long-term operational savings.
Cyber Resilient Architecture for Zero Trust IT environment & operations
Security is integrated into every phase of the PowerEdge lifecycle, including protected supply chain and factoryto-site integrity assurance. The Silicon-based root of trust anchors end-to-end boot resilience while Multi-Factor
Authentication (MFA) and role-based access controls safeguard trusted operations.
Vendor: Dell
Unit type: Server
Type: 19" 2 HE
Model: PowerEdge R770
HDD bays: 16x HotSwap HDD Bays SAS/S-ATA /NVMe Backplane
without selected hdds or trays are no hdd trays included in delivery
Optical drive: ohne
Networking: optional selectable
Internal interfaces:
16x 2,5" SAS*/SATA*/NVMe** Backplane
*optional SAS storage controller required
**optional NVMe onboard cabling or NVMe storage controller required
2x FCLGA4710 Intel CPU Socket XEON 6 Intel® Xeon® Processors up to 350W TDP
32x DDR5 ECC DIMM banks up to 8TB RAM
1x OCP 3.0 module Slot
1x USB 3.0
integrated TPM 2.0
Default Riser Config 6:
Riser 1:
1x PCIe 5.0 x16 (x16 lanes) - Full-Profile, Full-Length (double-width) (CPU1)
Riser 2:
1x PCIe 5.0 x16 (x16 lanes) - Full-Profile, Half-Length (CPU1)
Riser 3:
1x second OCP3 module slot (PCIe 5.0 x16) (CPU1)
Riser 4:
1x PCIe 5.0 x16 (x16 lanes) - Full-Profile, Half-Length (CPU0)
Riser 5:
1x PCIe 5.0 x16 (x16 lanes) - Full-Profile, Full-Length (double-width) (CPU0)
External interfaces:
Front:
1x USB-C
Rear:
1x VGA
2x USB 3.0
1x RJ-45 iDRAC
Videocard: onboard
Powerunits: up to 2x HotSwap power supply
Compatible operating systems:
Windows: Windows Server 2016, 2019, 2022*, 2025*; Windows 10, 11*
*compatible TPM module is required
Virtualisierung: vmware ; Citrix ; Microsoft Hyper-V ; Proxmox; Linux KVM
Linux Betriebssysteme: Linux Suse, Linux RHEL (RedHat), Debian, Fedora etc.
Tailored to fit complex data centers
The Dell PowerEdge R770 is a 2U, two-socket rack server delivering exceptional performance and scalability transforming complex IT requirements of today’s data centers. It combines enhanced compute power, flexible configurations, and energy efficiency to boost productivity. This makes it ideal for virtualization and microservices, cloud-native applications, large-scale analytics, and AI inferencing support to empower your infrastructure.
• Purpose-built to scale infrastructure to adapt seamlessly to technological changes, integrating new capabilities that support long-term growth and innovation.
• Powered by Intel® Xeon® 6 processors designed to meet diverse performance and efficiency requirements and offered with advanced GPU support.
• Enhanced I/O flexibility with optional front I/O configuration for seamless cold aisle serviceability.
• Dell Smart Power and Cooling solutions allow you to choose air cooled or DLC solutions to fit your IT and data center requirements.
• Configurable to suit diverse needs with industry standard open designs (DC-MHS) compliance.
